PoE / PoE+ RJ45 Jack Connector

PoE RJ45 JackB-TOP PoE RJ45 Jack Connectors are available in PoE/PoE+ versions that support Power over Ethernet functionally while allowing customers to manage power for PSE and PD. PoE rj45 jack with magnetics support both 10/100 and Gigabit ethernet applications.

B-TOP offers a range of Integrated PoE RJ45 Jack Connector that provide a cost-effective, plug-and-play solution for customers implementing PoE and PoE+. Available in single port (1*1), 2-port(2*1), 4-port (2*2), 8-port (2*4), 12-port(2*6), and 16-port(2*8) and with LED options.

Find more PoE RJ45 Jack pictures in the gallery.

PoE Magnetic RJ45 Jacks Features & Benefits

Integrated magneticsFilters common mode noise to provide signal integrity and protects PHY chip
Provides DC isolation
Offers low mode conversion
Integrated PD or PSE DesignPoE circuitry, transformers, chokes, capacitors and resistors, and other components with the connector
Eliminates complex design and testing, reduces time-to-market, saves PCB space
Fully shielded designsAdvanced EMI and ESD protection
Non PoE/PoE/PoE+ optionsProvides flexibility for a variety of design applications
IEEE 802.3 compliantEthernet 10/100/1000 compatible
IEEE 802.3af compliantPoE(Power over Ethernet) compatible
IEEE 802.3at compliantPoE+(Power over Ethernet Plus) compatible

Product list

Click to view additional details. If you are viewing this page on mobile device, it is recommended to rotate the screen.

Part NumberPortsSpeedSchematicPoELEDEMI SpringGold PlatingTemperatureDownloadNote
B50S(28-40)PF6-258A-P223-B52 1x1100MPF6-258APoEG/YYes6u"0 - 70PDF

B50(29-06)FP4-198-P613-B52 1x1100MFP4-198PoEGO/YNo6u"0 - 70PDF

B50(150-07)GP8-15-P623-F52 1x1GigabitGP8-15PoEGO/YYes6u"0 - 70PDF

B50(150-53)GP12-106-P623-F121x1GigabitGP12-106PoEGO/YYes6u"0 - 70PDF
B50(150-58)GP8-15-P623-F121x1GigabitGP8-15PoEGY/GYes6u"0 - 70PDF
B50(150-68)GP8-15C-P023-F521x1GigabitGP8-15CPoE+NoneYes6u"0 - 70PDF
B50(150-85)GP8-15A-P113-F521x1GigabitGP8-15APoEY/GNo6u"0 - 70PDF
B50(150-86)GP8-15A-P123-F52 1x1GigabitGP8-15APoE+Y/GYes6u"0 - 70PDF

B50(150-88)GP8-15-P623-F521x1GigabitGP8-15PoEGY/GYYes6u"0 - 70PDF
B50(150-90)GP8-218-P023-B521x1GigabitGP8-218PoENoneYes6u"0 - 70PDF
B50(151-02)FP4-150-P622-F121x1100MFP4-150PoEG/GOYes6u"0 - 70PDF
B50(151-03)FP4-150-P623-F121x1100MFP4-150PoEGO/GOYes6u"0 - 70PDF
B50(27-11)FP4-151-A623-B52 1x1100MFP4-151PoEGO/YYes6u"0 - 70PDF

B50(27-51)FP4-151-A613-B52 1x1100MFP4-151PoEGO/YNo6u"0 - 70PDF

B50(27-97)PF4-235-A223-B52 1x1100MPF4-235PoEG/YYes6u"0 - 70PDF

B50(27-100)PF4-244-A115-B521x1100MPF4-244PoEY/GNo30u"0 - 70PDF
B50(27-117)PF6-96-A223-B521x1100MPF6-96PoEG/YYes6u"0 - 70PDF
B50(27-118)PF4-260-A223-B521x1100MPF4-260PoEG/YYes6u"0 - 70PDF
B50(27-121)FP4-235-A223-B521x1100MFP4-235PoEG/YYes6u"0 - 70PDF
B50(27-122)PF4-269-A123-B521x1100MPF4-269PoEY/GYes6u"0 - 70PDF
B50(27-128)PF4-182-A213-B521x1100MPF4-182PoEG/YNo6u"0 - 70PDF
B50(27-137)PF4-153-A123-B521x1100MPF4-153PoEY/GYes6u"0 - 70PDF
B50(27-138)PF4-153-A123-B521x1100MPF4-153PoEY/GYes6u"0 - 70PDF
B50(27-142)PF4-269-A223-B52 1x1100MPF4-269PoEG/YYes6u"0 - 70PDF

B50(29-41)FP4-269-A023-B521x1100MFP4-269PoENoneYes6u"0 - 70PDF
B50(88-08)PF4-151-B023-B121x2100MPF4-151PoENoneYes6u"0 - 70PDF
B50(88-12)PF4-151B-B223-B121x2100MPF4-151BPoE+G/YYes6u"0 - 70PDF
B50(88-15)PF4-222-B323-B121x2100MPF4-222PoEG/GYes6u"0 - 70PDF
B50(88-16)PF4-222A-B323-B121x2100MPF4-222APoEG/GYes6u"0 - 70PDF
B50(511-21)PF6-96-A313-B521x1100MPF6-96PoEG/GNo6u"0 - 70PDF双扣
B50(511-32)PF6-96-A213-B521x1100MPF6-96PoEG/YNo6u"0 - 70PDF双扣
B50(512-12)FP4-252-A013-B521x1100MFP4-252PoENoneNo6u"0 - 70PDF
B50(512-18)PF4-196A-A013-B921x1100MPF4-196APoENoneNo6u"0 - 70PDF双扣 PIP
B50(650-11)FP4-178-A112-B121x1100MFP4-178PoEY/GNo6u"0 - 70PDF
B50(650-27)PF4-198-A612-B121x1100MPF4-198PoEGO/YNo6u"0 - 70PDF
B50(650-42)PF4-207-A113-B121x1100MPF4-207PoEY/GNo6u"0 - 70PDF
B50(650-61)PF4-151-A113-B121x1100MPF4-151PoEY/GNo6u"0 - 70PDF
B50(650-63)PF4-207-A113-B121x1100MPF4-207PoEY/GNo6u"0 - 70PDF
B50(660-09)PF4-147-A013-B121x1100MPF4-147PoENoneNo6u"0 - 70PDF
B59(57-50)FP4-236-1122-C122x1100MFP4-236PoEY/GYes6u"0 - 70PDF
B59(57-51)FP4-183-1323-C122x1100MFP4-183PoEG/GYes6u"0 - 70PDF
B59(57-57)FP4-248-1223-C12 2x1100MFP4-248PoEG/YYes6u"0 - 70PDF

B59(311-32)FP4-162-2123-C122x2100MFP4-162PoEY/GYes6u"0 - 70PDF
B59(311-38)FP4-182-2223-C122x2100MFP4-182PoEG/YYes6u"0 - 70PDF
B59(315-51)PF4-162-2023-C122x2100MPF4-162PoENoneYes6u"0 - 70PDF
B59(117-09)FP4-203-4022-C122x4100MFP4-203PoENoneYes6u"0 - 70PDF
B59(117-11)FP4-162-4026-C122x4100MFP4-162PoENoneYes50u"0 - 70PDF
B59(119-01)FP4-237-4125-C122x4100MFP4-237PoEY/GYes30u"0 - 70PDF防雷
B59(119-02)FP4-238-4125-C122x4100MFP4-238PoEY/GYes30u"0 - 70PDF防雷
B59(119-03)FP4-242-4123-C122x4100MFP4-242PoEY/GYes6u"0 - 70PDF防雷
B59(119-05)FP4-242A-4125-C122x4100MFP4-242APoE+Y/GYes30u"0 - 70PDF
B59(119-06)FP4-283-4123-C122x4100MFP4-283PoEY/GYes6u"0 - 70PDF
B59(123-13)FP4-162-4222-C122x4100MFP4-162PoEG/YYes6u"0 - 70PDF
B59(123-26)PF4-178-4623-C122x4100MPF4-178PoEYG/YGYes6u"0 - 70PDF
B59(123-33)PF4-236B-4125-C922x4100MPF4-236BPoEY/GYes30u"0 - 70PDF
B59(123-34)FP4-241-4223-C122x4100MFP4-241PoEG/YYes6u"0 - 70PDF
B59(123-40)PF4-162-4223-C922x4100MPF4-162PoEG/YYes6u"0 - 70PDF
B59(123-43)PF4-178-4223-C122x4100MPF4-178PoEG/YYes6u"0 - 70PDF
B59(123-44)FP4-162-4323-C122x4100MFP4-162PoEG/GYes6u"0 - 70PDF
B60(115-19)PF6-230-4023-C122x4100MPF6-230PoENoneYes6u"0 - 70PDF横排脚
B59(175-05)FP4-162-6022-C122x6100MFP4-162PoENoneYes6u"0 - 70PDF
B59(176-02)FP4-162-6722-C122x6100MFP4-162PoEG/YYes6u"0 - 70PDF
B59(176-05)FP4-162-6323-C122x6100MFP4-162PoEG/GYes6u"0 - 70PDF
B59(46-01)GP8-99-1623-C122x1GigabitGP8-99PoEGY/GYYes6u"0 - 70PDF
B59(46-10)GP8-19F-1223-C122x1GigabitGP8-19FPoE+G/YYes6u"0 - 70PDF
B59(46-11)GP8-19-1123-C122x1GigabitGP8-19PoEY/GYes6u"0 - 70PDF
B59(46-12)GP8-19-1623-C122x1GigabitGP8-19PoEGO/GOYes6u"0 - 70PDF
B59(46-15)GP8-19-1023-C122x1GigabitGP8-19PoENoneYes6u"0 - 70PDF
B59(46-17)GP8-19B-1623-C122x1GigabitGP8-19BPoE+GY/GYYes6u"-40 - 85PDF
B59(46-18)GP8-19B-1613-C12 2x1GigabitGP8-19BPoE+GY/GYNo6u"-40 - 85PDF

B59(46-22)GP8-19H-1613-C122x1GigabitGP8-19HPoEGY/GYNo6u"0 - 70PDF防雷
B59(46-23)GP8-19B-1613-C122x1GigabitGP8-19BPoE+GY/GYNo6u"-40 - 85PDF

B59(46-25)GP8-141-1613-C12 2x1GigabitGP8-141PoE+GY/GYNo6u"0 - 70PDF

B59(46-27)GP8-19D-1625-C122x1GigabitGP8-19PoEGY/GYYes30u"0 - 70PDF
B59(46-29)GP8-19D-1113-C122x1GigabitGP8-19DPoEY/GNo6u"0 - 70PDF
B59(46-30)GP8-19B-1623-C922x1GigabitGP8-19BPoE+GO/GYes6u"0 - 70PDF
B59(46-31)GP8-67-1113-C122x1GigabitGP8-67PoE+Y/GNo6u"0 - 70PDF
B59(46-35)GP8-19N-1223-C122x1GigabitGP8-19PoEG/YYes6u"0 - 70PDF
B59(46-36)GP8-213-1613-C12 2x1GigabitGP8-213PoEG/OGNo6u"0 - 70PDF

B59(46-37)GP8-19D-1213-C122x1GigabitGP8-19DPoEG/YNo6u"0 - 70PDF
B59(46-38)GP8-19H-1213-C122x1GigabitGP8-19PoEG/YNo6u"0 - 70PDFTVS
B59(46-39)GP8-141-1123-C122x1GigabitGP8-141PoEY/GYes6u"0 - 70PDFGAS
B59(46-42)GP8-214-1223-C122x1GigabitGP8-214PoEG/YYes6u"0 - 70PDF
B59(46-111)GP8-19B-1023-C122x1GigabitGP8-19PoENoneYes6u"0 - 70PDF
B59(46-116)GP8-232-1023-C122x1GigabitGP8-232PoE++NoneYes6u"-40 - 85PDF
B59(46-117)GP8-19P-1223-C122x1GigabitGP8-19PoEG/YYes6u"0 - 70PDF
B59(46-118)GP8-188-1623-C122x1GigabitGP8-188PoEGY/GYes6u"0 - 70PDF
B59(46-119)GP8-232-1223-C122x1GigabitGP8-232PoE++G/YYes6u"-40 - 85PDF
B59(318-03)GP8-19-2623-C122x2GigabitGP8-19PoEGY/GYYes6u"0 - 70PDF
B59(318-05)GP8-109A-2623-C122x2GigabitGP8-109APoEGY/GYYes6u"0 - 70PDF
B59(318-07)GP8-19A-2023-C122x2GigabitGP8-19APoENoneYes6u"0 - 70PDF
B59(318-08)GP8-19B-2623-C122x2GigabitGP8-19BPoE+GY/GYYes6u"-40 - 85PDF
B59(318-10)GP8-103B-2223-C122x2GigabitGP8-103BPoEG/YYes6u"-40 - 85PDF
B59(318-16)GP8-19A-2123-C122x2GigabitGP8-19APoEY/GYes6u"0 - 70PDF
B59(318-20)GP8-19B-2623-C122x2GigabitGP8-19BPoE+GO/GOYes6u"-40 - 85PDF
B59(318-61)GP8-19B-2023-C122x2GigabitGP8-19BPoE+NoneYes6u"-40 - 85PDF
B59(318-63)GP8-70-2023-C122x2GigabitGP8-70PoENoneYes6u"0 - 70PDF
B59(318-64)GP8-70-2023-C922x2GigabitGP8-70PoENoneYes6u"0 - 70PDFPIP
B59(318-65)GP8-70B-2024-C922x2GigabitGP8-70BPoENoneYes15u"-40 - 85PDFwith GAS tube, PIP
B59(318-67)GP8-203-2023-C122x2GigabitGP8-203PoENoneYes6u"0 - 70PDF
B59(112-32)GP8-220-4623-C122x4GigabitGP8-220PoEYG/YGYes6u"0 - 70PDF
B59(112-33)GP8-160-4223-C122x4GigabitGP8-160PoEG/YYes6u"0 - 70PDF
B59(118-03)GP8-19A-4223-C122x4GigabitGP8-19APoEG/YYes6u"0 - 70PDF
B59(118-05)GP8-19A-4023-C122x4GigabitGP8-19APoENoneYes6u"0 - 70PDF
B59(118-11)GP8-103F-4023-C122x4GigabitGP8-103FPoENoneYes6u"0 - 70PDF
B59(118-15)GP8-103F-4623-C122x4GigabitGP8-103FPoEYG/YGYes6u"0 - 70PDF中间LED
B59(118-43)GP8-139-4223-C12 2x4GigabitGP8-139PoEG/YYes6u"0 - 70PDF

B59(118-43)GP8-139-4223-C12

B59(118-49)GP8-109-4725-C122x4GigabitGP8-109PoEGO/GOYes30u"0 - 70PDF单排中间LED
B59(118-50)GP8-153-4625-C122x4GigabitGP8-153PoEGY/GYYes30u"0 - 70PDF中间LED
B59(118-53)GP8-19B-4725-C122x4GigabitGP8-19BPoE+GO/GOYes30u"-40 - 85PDF
B59(118-55)GP8-19E-4624-C122x4GigabitGP8-19EPoE+OG/OGYes15u"0 - 70PDF中间LED
B59(118-56)GP8-19E-4623-C922x4GigabitGP8-19EPoEOG/OGYes6u"0 - 70PDF中间LED
B59(118-57)GP8-19G-4725-C122x4GigabitGP8-19GPoEGO/GOYes30u"0 - 70PDF单排中间LED
B59(118-58)GP8-19B-4623-C122x4GigabitGP8-19BPoE+GO/GOYes6u"-40 - 85PDF
B59(118-59)GP8-109B-4725-C122x4GigabitGP8-109BPoEGO/GOYes30u"-40 - 85PDF单排中间LED
B59(118-67)GP8-161A-4323-C122x4GigabitGP8-161APoE+G/GYes6u"0 - 70PDF
B59(118-70)GP8-153-4625-C122x4GigabitGP8-153PoEGO/GOYes30u"0 - 70PDF
B59(118-71)GP8-161A-4224-C122x4GigabitGP8-161APoE+G/YYes15u"0 - 70PDF
B59(118-72)GP8-19G-4725-C122x4GigabitGP8-19GPoEG/YYes30u"0 - 70PDF单排中间LED
B59(118-74)GP8-103F-4223-C122x4GigabitGP8-103FPoEG/YYes6u"0 - 70PDF中间LED
B59(118-76)GP8-19J-4225-C122x4GigabitGP8-19JPoEG/YYes30u"0 - 70PDF中间LED
B59(118-77)GP8-19B-4223-C122x4GigabitGP8-19BPoE+G/YYes6u"-40 - 85PDF
B59(118-78)GP8-19B-4623-C122x4GigabitGP8-19BPoE+OG/OGYes6u"-40 - 85PDF
B59(118-79)GP8-139A-4223-C12 2x4GigabitGP8-139APoE+G/YYes6u"0 - 70PDF

B59(118-82)GP8-139-4623-C122x4GigabitGP8-139PoEG/GOYes6u"0 - 70PDF
B59(118-83)GP8-19A-4623-C122x4GigabitGP8-19APoEG/GOYes6u"0 - 70PDF
B59(118-92)GP8-209-4723-C122x4GigabitGP8-209PoEGO/GOYes6u"0 - 70PDF单排中间LED
B59(118-93)GP8-19K-4023-C122x4GigabitGP8-19KPoENoneYes6u"0 - 70PDF
B59(118-95)GP8-67B-4123-C122x4GigabitGP8-67BPoEY/GYes6u"-40 - 85PDF
B59(118-96)GP8-139A-4223-C12 2x4GigabitGP8-139APoE+G/YYes6u"0 - 70PDF

B59(118-97)GP8-70-4323-C122x4GigabitGP8-70PoEG/GYes6u"0 - 70PDF
B59(118-98)GP8-103I-4323-C122x4GigabitGP8-103IPoEG/GYes6u"0 - 70PDF
B59(118-99)GP8-215-4123-C122x4GigabitGP8-215PoEY/GYes6u"0 - 70PDF
B59(118-100)GP8-216-4123-C122x4GigabitGP8-216PoEY/GYes6u"0 - 70PDF
B59(118-101)GP8-103I-4123-C122x4GigabitGP8-103IPoEY/GYes6u"0 - 70PDF
B59(118-102)GP8-222-4126-C122x4GigabitGP8-222PoEY/GYes50u"0 - 70PDF中间LED
B59(118-103)GP8-19H-4223-C122x4GigabitGP8-19HPoEG/YYes6u"0 - 70PDF

TVS

B59(118-104)GP8-232-4013-C122x4GigabitGP8-232PoENoneYes6u"0 - 70PDF
B59(118-105)GP8-237-4223-C122x4GigabitGP8-237PoEG/YYes6u"0 - 70PDF
B59(118-108)GP8-153-4323-C122x4GigabitGP8-153PoEG/GYes6u"0 - 70PDF
B59(118-109)GP8-19N-4623-C122x4GigabitGP8-19NPoEO/GYes6u"0 - 70PDF
B59(118-110)GP8-67D-4123-C122x4GigabitGP8-67DPoEY/GYes6u"0 - 70PDF
B59(118-111)GP8-239-4123-C122x4GigabitGP8-239PoEY/GYes6u"0 - 70PDF
B59(118-112)GP8-188-4623-C122x4GigabitGP8-188PoEGY/GYes6u"0 - 70PDF
B59(118-113)GP8-139B-4623-C122x4GigabitGP8-139BPoEG/GOYes6u"-40 - 85PDF

TVS

B59(169-02)GP8-103F-6023-C122x6GigabitGP8-103FPoENoneYes6u"0 - 70PDF
B59(169-03)GP8-19A-6023-C122x6GigabitGP8-19PoENoneYes6u"0 - 70PDF
B59(169-05)GP8-19A-6223-C12 2x6GigabitGP8-19APoEG/YYes6u"0 - 70PDF

B59(169-06)GP8-115U-6023-C122x6GigabitGP8-115UPoENoneYes6u"0 - 70PDF
B59(169-08)GP8-103A-6023-C122x6GigabitGP8-103APoENoneYes6u"0 - 70PDF
B59(169-10)GP8-19A-6123-C12 2x6GigabitGP8-19APoEY/GYes6u"0 - 70PDF

B59(169-12)GP8-19-6023-C122x6GigabitGP8-19PoENoneYes6u"0 - 70PDF
B59(169-21)GP8-149-6023-C122x6GigabitGP8-149PoENoneYes6u"0 - 70PDF
B59(169-24)GP8-19K-6023-C122x6GigabitGP8-19KPoENoneYes6u"0 - 70PDF
B59(169-27)GP8-19B-6023-C122x6GigabitGP8-19BPoE+NoneYes6u"-40 - 85PDF
B59(169-30)GP8-19D-6123-C12 2x6GigabitGP8-19DPoEY/GYes6u"0 - 70PDF

B59(169-31)GP8-139-6623-C122x6GigabitGP8-139PoEGY/GYYes6u"0 - 70PDF
B59(169-33)GP8-19D-6123-C122x6GigabitGP8-19DPoEY/GYes6u"0 - 70PDF
B59(169-35)GP8-19D-6623-C122x6GigabitGP8-19DPoEGO/YYes6u"0 - 70PDF
B59(169-61)GP8-103A-6623-C122x6GigabitGP8-103APoEGY/GYYes6u"0 - 70PDF中间LED
B59(169-64)GP8-109-6625-B922x6GigabitGP8-109PoEGO/GOYes30u"0 - 70PDF
B59(169-66)GP8-19B-6223-C12 2x6GigabitGP8-19BPoE+G/YYes6u"-40 - 85PDF

B59(169-79)GP8-103F-6123-C122x6GigabitGP8-103FPoEY/GYes6u"0 - 70PDF
B59(169-81)GP8-189-6223-C122x6GigabitGP8-189PoEG/YYes6u"0 - 70PDF
B59(169-83)GP8-19B-6623-C122x6GigabitGP8-19BPoE+GO/GOYes6u"-40 - 85PDF
B59(169-85)GP8-170A-6023-C122x6GigabitGP8-170APoENoneYes6u"0 - 70PDF
B59(171-01)GP8-19A-6023-C122x6GigabitGP8-19APoENoneYes6u"0 - 70PDFsolder-free
B59(180-01)GP4-162A-6023-C122x6GigabitGP4-162APoENoneYes6u"0 - 70PDFpin distance 3.0mm
B59(180-02)GP4-162A-6023-C122x6GigabitGP4-162APoENoneYes6u"0 - 70PDFpin distance 3.0mm
B59(198-01)GP8-99-8623-C122x8GigabitGP8-99PoEGY/GYYes6u"0 - 70PDF中间灯
B59(199-02)GP8-19-8023-C122x8GigabitGP8-19PoENoneYes6u"0 - 70PDF
B59(199-03)GP8-103E-8023-C12 2x8GigabitGP8-103EPoE+NoneYes6u"0 - 70PDF

with fuse

B59(199-06)GP8-19-8123-C122x8GigabitGP8-19PoEY/GYes6u"0 - 70PDF
B59(199-09)GP8-19B-8623-C122x8GigabitGP8-19BPoE+GY/GYYes6u"-40 - 85PDF
B59(199-10)GP8-139-8223-C122x8GigabitGP8-139PoEG/YYes6u"0 - 70PDF

PoE RJ45 Applications

  • 1. Data/ Tele communications
    • PoE power injectors
    • Low PoE port-count switches
    • Server peripheral communication and power
  • 2. Security
    • IP enabled devices (security devices), such as IP Camera
    • Wireless access points
  • 3. Industrial
    • Building automation
  • 4. Consumer / SOHO
    • Desktop computers
    • Set-top boxes
    • IP Phone
